Troubleshooting BIOS Video Issues: A Guide for First-Time PC Builders
Building a new PC is an exciting venture, but it can also present a few challenges, especially when it comes to troubleshooting video output issues. If you’re facing a situation where you don’t see any video output after connecting just the power supply, you’re not alone. Here’s a case study to shed some light on what to check and how to proceed.
The Build in Question
Imagine putting together a powerful PC setup featuring:
- Motherboard: MAG B550 TOMAHAWK MAX WIFI
- CPU: Ryzen 9 5900X
- GPU: GeForce RTX 3090
- RAM: 4 x Micron MTA18ASF2G72PDZ-3G2R1 16GB DDR4 3200MHz (ECC)
- Storage: 1 x SAMSUNG MZVLB2T0HALB-000L7
In this case, the builder omitted an important step: updating the BIOS prior to installing the Ryzen 9 5900X. After booting up the assembled components, they encountered an issue where no video was displayed via HDMI on either the motherboard or the graphics card.
The Troubleshooting Journey
Realizing that a BIOS update was necessary, the builder successfully flashed the BIOS with version 7C91v28 while all components were still installed. However, they still experienced no video output. While the system provided power (all fans and LEDs appeared to function normally), a frustrating red CPU light illuminated on the motherboard, indicating a potential issue.
In an attempt to rectify the situation, the builder explored multiple BIOS versions, including one from October 13, 2023, specifically designed to support Ryzen 5000 series CPUs. They diligently followed the BIOS update process, utilizing the designated USB port for updates and ensuring the stick’s LED indicator confirmed data access for more than five minutes.
Common Questions and Considerations
At this point, the builder was left wondering about a few critical aspects:
- Should there be any indications of a failed BIOS POST on the display output, even with minimal components connected?
- Does the motherboard possess integrated graphics, or is it entirely reliant on the CPU for video output?
Key Takeaways for Builders
- Check for Integrated Graphics: Many motherboards, especially those designed for more powerful CPUs, may not have integrated graphics. This means that the
Share this content:
When troubleshooting a BIOS video issue with only power connected, it’s important to consider a few key factors. First, verify whether your motherboard has integrated graphics support. Many AMD motherboards do not feature integrated graphics; instead, they rely solely on a compatible CPU with built-in graphics or a dedicated GPU for video output.
If you’re using a CPU like the Ryzen 9 5900X, note that it does not have integrated graphics. Therefore, connecting only power may result in no video output unless a discrete graphics card is installed and properly seated. Also, ensure that your graphics card is compatible and supported by the motherboard, and that power connectors are securely attached.
The prominent CPU LED indicates a possible compatibility or power issue related to the CPU or its installation. Double-check the CPU socket for proper seating, clear any bent pins, and confirm that the BIOS version supports your CPU. Since BIOS updates are crucial for compatibility with newer CPUs, it’s advisable to perform the update with the minimum essential components (CPU, RAM, GPU if necessary) and follow the motherboard manufacturer’s clear instructions for BIOS flashing.
In cases where minimal components are connected and no POST or video output occurs, consider performing a CMOS reset or BIOS default load. Additionally, testing with a different GPU or minimal hardware setup can help isolate the problem. If the CPU light remains on after these steps, contact the motherboard support team for further diagnostics or consider testing the CPU in
